Neon flex cob led strip rgbic lights

  • Neon flex cob led strip rgbic lights
  • Neon flex cob led strip rgbic lights
  • Neon flex cob led strip rgbic lights
  • Neon flex cob led strip rgbic lights

Neon flex cob led strip rgbic lights

    Packaging: carton
    Transportation: Ocean,Air,Express,Express
    Supply Ability: 10000/day
    Port: yantian

Product Description

COB strip light COB soft light bar COB flexible strip light flip chip COB strip light


dual warm white nature white flex led cob strip 512led 24v 12w cob flexible led strips ip20 with connector
Specification Light bar parameters
Brand Huangtai
Type HT-SX512F008W24-12-COB
LED QTY 512 LED/m
Color

warm white/nature white

CRI Ra85
Input voltage 24v
Power 12w/m
Luminous officiency 96-98lm/m
Luminous brightness 1300k-1600k
Board width 8mm
Color temperature dual white
Cuttable length 63mm
Working lifetime 50000h
Working temperature -20℃-40℃
Warranty 3 years
dual warm white nature white flex led cob strip 512led 24v 12w cob flexible led strips ip20 with connectordual warm white nature white flex led cob strip 512led 24v 12w cob flexible led strips ip20 with connectordual warm white nature white flex led cob strip 512led 24v 12w cob flexible led strips ip20 with connectordual warm white nature white flex led cob strip 512led 24v 12w cob flexible led strips ip20 with connectordual warm white nature white flex led cob strip 512led 24v 12w cob flexible led strips ip20 with connectordual warm white nature white flex led cob strip 512led 24v 12w cob flexible led strips ip20 with connectordual warm white nature white flex led cob strip 512led 24v 12w cob flexible led strips ip20 with connectordual warm white nature white flex led cob strip 512led 24v 12w cob flexible led strips ip20 with connector






Advantages of the new soft light bar

dual warm white nature white flex led cob strip 512led 24v 12w cob flexible led strips ip20 with connector

1.Widely used, easy to install and maintain, long service life

2.Very flexible, easy to bend into different shapes, various white light options
3.COB Design, with more chips on PCB, more even light.
4.Up to 512 chips on 1 meter PCB, only 2.0mm space between chips.
5.Cuttable at every 63mm length. Form a circuit without affecting other circuites.
6.Efficiency up to 100Lm/W.
7.Ra 90 also available.
8. Can be customized according to customer requirements

IP Rating

Details

IP20


IP65

Injected with Silicone Tube

IP67

IP67 Extrusion, Integrated Silicone

IP68

Solid Integrated Silicone glue, or silicone glue with silicone tube





dual warm white nature white flex led cob strip 512led 24v 12w cob flexible led strips ip20 with connector



Installation Ways

* The max running length is 6 meters, for over 6 meters please connect in parallel.

* Make sure of the total watts of COB Strip lights is less than 80% of the power supply's
max output.
* Match the polarities according to the mark ('+' and '-') in the PCB while connecting.


dual warm white nature white flex led cob strip 512led 24v 12w cob flexible led strips ip20 with connector

dual warm white nature white flex led cob strip 512led 24v 12w cob flexible led strips ip20 with connector
